Holographic Transparent led screen P3.9 P6.25

Holographic Transparent led screen P3.9 P6.25
Holographic Transparent led screen
Holographic Transparent led screen P3.9 P6.25
Holographic Transparent led screen Supplier

Holographic Transparent led screen P3.9 P6.25

Item P3.91-3.91 P6.25-6.25
Pixel Pitch(mm) 3.91:3.91 6.25-62.5
Cabinet Resolution(W×H)
Cabinet Size(mm) 1000mm*250mm/1500*250mm
Cabinet Weight(kg/cabinet) 1.5
Cabinet Material Aluminium profiles
IP Rating Indoor IP20,Outdoor IP65
White Balance Brightness(nits) Indoor 0~1200cd/m²,Outdoor 4000-6500cd/m²
Color Processor(bit) 12-16
Color Temperature(K) 6500-9000
Visual Angle(H/V) 150°/ 150°
Chromaticity uniformity Within ±0.003Cx, Cy

Description

Holographic Transparent led screen P3.9 P6.25

LED Holographic screen
Item Unit Parameters
Pitch mm V3.91mm   H3.91mm
LED SMD Black 1717 ic intergrated
Resolution  dot/m² 65536
Cabinet size mm 1000mm*250mm/1500*250mm
Brightness cd /m² 3000cd/1500cd
Unit weight/cabinet kg/pcs 1.5kg
Unit weight kg /m² 6kg
Thickness mm 65
Transparency rate % 92
Max/Average power consumption w/m² 800/200
Grey bit 16
Contrast 9000：1
Color Temp K 6500-9300K
Brightness adjust level 256
View angle ° ≥140/≥120
Best view distance m 10-3000
Refresh rate hz ≥3840
Control Sync/Async
Control distance 100m(RJ45) 500M(Fiber multi-mode) 10km(Fiber single mode)
Driver Constant driver
HD 1920*1080
Life ≥100000 hours
Cooling air
Working/Store temp -20°c ~+60°c  /  -55°c ~+100°c
Working humidity RH 10-90%
Installation way against glass wall
Fast installation Yes
Maintenance way Front or back
